Thread: 1940 Ford Pickup




Reply To Thread
Page 64 of 73 FirstFirst ... 14 54 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 ... LastLast
Results 946 to 960 of 1085
  1. #946
    Navy7797 is offline CHR Member Visit my Photo Gallery
    Join Date
    Mar 2013
    Location
    Seguin
    Car Year, Make, Model: 1940 Ford p/u 1937 Caddy Coupe
    Posts
    767

    More delays, this time a sad delay. My painter's mother-in-law passed away and family always comes first. We only have so many summers left so may you all have the best ones ever !
    34_40, rspears, stovens and 2 others like this.

  2. #947
    rspears's Avatar
    rspears is offline CHR Member/Contributor Visit my Photo Gallery
    Join Date
    Sep 2007
    Location
    Gardner, KS
    Car Year, Make, Model: '33 HiBoy Coupe, '32 HiBoy Roadster
    Posts
    11,115

    Sorry for the delay, but family first for sure.
    Roger
    Enjoy the little things in life, and you may look back one day and realize that they were really the BIG things.

  3. #948
    34_40's Avatar
    34_40 is offline CHR Member Visit my Photo Gallery
    Join Date
    Sep 2007
    Location
    New Bedford
    Car Year, Make, Model: 34 Ford 3W Coupe Replica
    Posts
    14,673

    HMmm. maybe I can make a post?? the page could be found??

    anyway, I agree, the truck will wait - the family must come first. Hope they can find some peace.

  4. #949
    Navy7797 is offline CHR Member Visit my Photo Gallery
    Join Date
    Mar 2013
    Location
    Seguin
    Car Year, Make, Model: 1940 Ford p/u 1937 Caddy Coupe
    Posts
    767

    Had a water temp sensor problem, guessing it was the Teflon tape. The gauge was off by 30 degree's compared to the sniper EFI ECU.. Temp gauge would only go to 150 degrees . I drilled a hole in the sensor bushing and soldered a ground wire to it, bolted other end problem solved . My painter is back working on my truck too.
    Last edited by Navy7797; 05-18-2021 at 04:49 PM.

  5. #950
    rspears's Avatar
    rspears is offline CHR Member/Contributor Visit my Photo Gallery
    Join Date
    Sep 2007
    Location
    Gardner, KS
    Car Year, Make, Model: '33 HiBoy Coupe, '32 HiBoy Roadster
    Posts
    11,115

    Nice fix, but why not just remove the Teflon tape?
    NTFDAY and pepi like this.
    Roger
    Enjoy the little things in life, and you may look back one day and realize that they were really the BIG things.

  6. #951
    pepi's Avatar
    pepi is offline CHR Member/Contributor Visit my Photo Gallery
    Join Date
    Dec 2006
    Location
    Woodstock
    Car Year, Make, Model: 34,stroker,32pu,2020 MustangGTpp2
    Posts
    1,109

    Agree, an awl or scribe will work .
    I have two brains, one is lost and the other is out looking for it

  7. #952
    Navy7797 is offline CHR Member Visit my Photo Gallery
    Join Date
    Mar 2013
    Location
    Seguin
    Car Year, Make, Model: 1940 Ford p/u 1937 Caddy Coupe
    Posts
    767

    Quote Originally Posted by rspears View Post
    Nice fix, but why not just remove the Teflon tape?
    Well I could have tried that but I thought it would leak anti freeze , the sensor/bushing screws into an aluminum block below the thermostat housing. Bad/good thing I now have and extra temp sensor because I replaced it 1st thinking that was the problem.

  8. #953
    rspears's Avatar
    rspears is offline CHR Member/Contributor Visit my Photo Gallery
    Join Date
    Sep 2007
    Location
    Gardner, KS
    Car Year, Make, Model: '33 HiBoy Coupe, '32 HiBoy Roadster
    Posts
    11,115

    Quote Originally Posted by Navy7797 View Post
    Well I could have tried that but I thought it would leak anti freeze , the sensor/bushing screws into an aluminum block below the thermostat housing. Bad/good thing I now have and extra temp sensor because I replaced it 1st thinking that was the problem.
    With a tapered thread and two relatively soft metals I'd say the chances of a leak are slim, but what I do in those cases where I wonder is only put teflon tape on the bottom half of the threaded adapters so that the top threads are metal to metal, ensuring the ground connection. Different ways to achieve the same end (started to say "skin the cat" but I guess that's offensive these days.... )
    NTFDAY and stovens like this.
    Roger
    Enjoy the little things in life, and you may look back one day and realize that they were really the BIG things.

  9. #954
    36 sedan's Avatar
    36 sedan is offline CHR Member Visit my Photo Gallery
    Join Date
    Apr 2012
    Location
    american canyon
    Car Year, Make, Model: 36 Ford Sedan, 23 T Bucket
    Posts
    1,899

    Quote Originally Posted by Navy7797 View Post
    Had a water temp sensor problem, guessing it was the Teflon tape. The gauge was off by 30 degree's compared to the sniper EFI ECU.. Temp gauge would only go to 150 degrees . I drilled a hole in the sensor bushing and soldered a ground wire to it, bolted other end problem solved . My painter is back working on my truck too.
    JMHO, this is proof positive and contrary to some popular beliefs, the tape can indeed insulate the electrical connection or at least impede its ground conductivity (jumper wire proofing it).

    There has actually been a long standing argument among some that this can NOT happen, lol. And yet, here it is, an electrical impedance of the ground connection to the sensor.
    Usually, the brass threads on the sensor being tapered and soft are enough to create a good seal without any sealants required. Occasionally though if you must use a sealant it is best to use an automotive grade liquid type sealant, applied to the outside (male) threads only, ensuring a good ground connection and seal.

  10. #955
    40FordDeluxe's Avatar
    40FordDeluxe is offline CHR Member Visit my Photo Gallery
    Join Date
    Apr 2011
    Location
    Prairie City
    Car Year, Make, Model: 40 Ford Deluxe, 68 Corvette, 72&76 K30
    Posts
    7,297
    Blog Entries
    1

    It really depends on how good the threads are machined on the fittings if you get a perfect seal or not. Most always tend to leak in my experience with no sealant on the threads. I've found the liquid type sealant works best though.

    .
    Ryan
    1940 Ford Deluxe Tudor 354 Hemi 46RH Electric Blue w/multi-color flames, Ford 9" Residing in multiple pieces
    1968 Corvette Coupe 5.9 Cummins Drag Car 11.43@130mph No stall leaving the line with 1250 rpm's and poor 2.2 60'
    1972 Chevy K30 Longhorn P-pumped 24v Compound Turbos 47RH Just another money pit
    1971 Camaro RS 5.3 BTR Stage 3 cam, SuperT10
    Tire Sizes

  11. #956
    Navy7797 is offline CHR Member Visit my Photo Gallery
    Join Date
    Mar 2013
    Location
    Seguin
    Car Year, Make, Model: 1940 Ford p/u 1937 Caddy Coupe
    Posts
    767

    Doors are finally done, electric windows with light gray glass.

  12. #957
    v8nutz's Avatar
    v8nutz is offline CHR Member Visit my Photo Gallery
    Join Date
    Nov 2016
    Location
    rocklin
    Posts
    632

    That's purdy!
    rspears likes this.

  13. #958
    34_40's Avatar
    34_40 is offline CHR Member Visit my Photo Gallery
    Join Date
    Sep 2007
    Location
    New Bedford
    Car Year, Make, Model: 34 Ford 3W Coupe Replica
    Posts
    14,673

    /\ /\ What he said /\ /\ /\ Gonna look great!
    Dave Severson and rspears like this.

  14. #959
    Navy7797 is offline CHR Member Visit my Photo Gallery
    Join Date
    Mar 2013
    Location
    Seguin
    Car Year, Make, Model: 1940 Ford p/u 1937 Caddy Coupe
    Posts
    767

    Thanks for the positive comments !
    34_40 likes this.

  15. #960
    glennsexton's Avatar
    glennsexton is offline CHR Member/Contributor Visit my Photo Gallery
    Join Date
    Mar 2005
    Location
    Tigard
    Car Year, Make, Model: 63 Nova SS
    Posts
    2,582

    Quote Originally Posted by 40FordDeluxe View Post
    It really depends on how good the threads are machined on the fittings if you get a perfect seal or not. Most always tend to leak in my experience with no sealant on the threads. I've found the liquid type sealant works best though.

    .
    I have used RectorSeal No. 5 for years on water temperature sensors with total success. It has great sealing properties, lubricates, and remains soft so removal of a water sensor is easier. I do not believe it has any dielectric characteristics as evidenced by a continuity reading of zero ohms between the brass base of the water sensor and the aluminum manifold.
    "Where the people fear the government you have tyranny. Where the government fears the people you have liberty." John Basil Barnhil
